The ELSA Pro 4K series are the best solution for those space-constricted installed sound reinforcement applications where sonic quality and system performance are required on a long-term full-power operating basis. Implementing ELSA high efficiency Professional Power Amplifier provide an unprecedented acoustic fidelity on the Professional Power Amplifiers range
4K |
||
|---|---|---|
| 2Ω Stereo Power** | 2000W X 2 | |
| Freq. Response | 20Hz-20KHz(±0.5dB) | |
| THD+N | ><0.05% | |
| Slew rate | >20V/us | |
| Damping factor | >>450@8Ω | |
| Dynamic range | >90dB | |
| S/N rate | >80dB | |
| Input sensitivity | 0.775V rms | |
| Input Impedance (Bal./unbal.) | Balance 20K/unbalance 10K | |
| Output circuit class | 2 steps class H | 3 steps class H | |
| Hi-Pass Filter | 30Hz@3dB | |
| Lo-Pass Filter | 150Hz@3dB | |
| Protection | Clip/limit, DC short circuit, switch on/off zero impact, soft start, VHF | |
| Cooling air-flow | Airflow from front panel to rear panel | |
| Input voltage/frequency | -220V±10%/50Hz | |
